data
- Year of construction
- 1959
- number of manuals
- 1
- manuals
- Kontra F-d''''
- pedal
- C-g'
- system
- mechanical
- stop action mechanism
- mechanical
- Register
- 9
- Principle-base
- 4
- height
- 385 cm
- width
- 350 cm
- depth
- 194 cm
-
disposition
Manual (Bass: Kontra F-a° / Diskant: b°⁻d''''):
Rohrflöte 8'
Prinzipal 4'
Gedackt 4'
Gemshorn 2' // Octave 2'
Octave 1' // Mixtur 4f.
Mixtur 3f. // Sesquialtera 2f. 8/3' und 8/5'
Tertian 2f. 8/5' und 8/6' // Dulcianregal 16'
Pedal:
Gedacktbass 16'
Bassflöte 8'
-
couplers
I/P
Damping: Manual via cabinet doors and pedal via blinds that can be closed
-
remarks
Height of the middle section: 385 cm
Height of the side sections: 325 cm
Disposition, arrangement of the works, mensuration, and case design: OSV Herbert Schulze and physicist Dr. Karl Theodor Kühn (Berlin)
The organ has been regularly maintained and is in good condition. Cleaning would probably be necessary.
There are many old letters and documents that document the difficult process of building this organ.
An instrument definitely worth preserving.
